| Model | JYWXJ-0.6-15.8 | JYWXJ-1.1-15.8 | JYWXJ-1.4-15.8 |
Motor Power | 5.5kW | 11kW | 15kW |
| 7.5HP | 15HP | 20HP | |
| Discharge Pressure | 1.58MPa | 1.58MPa | 1.58MPa |
| Discharge Capacity | 600L/min | 1100L/min | 1400L/min |
Voltage | Three-Phase | Three-Phase | Three-Phase |
| 380V | 380V | 380V | |
| Frequency | 50/60Hz | 50/60Hz | 50/60Hz |
| Dimension | 1870*540*1300mm | 1870*600*1380mm | 1870*600*1380mm |
| Weight | 320kg | 415kg | 415kg |
| Tank | 340L | 340L | 340L |
| Environment Temperature | -5℃-45℃ | -5℃-45℃ | -5℃-45℃ |
| Noise | 55-68dB | 58-68dB | 58-70dB |
| Cooling Mode | Air colding | Air colding | Air colding |
| Oil Carryover of Discharged Air | ≤0.1PPM | ≤0.1PPM | ≤0.1PPM |
| Drive Mode | Coaxial integration | Coaxial integration | Coaxial integration |
| Control Mode | Frequency conversion | Frequency conversion | Frequeney conversion |
| Solenoid Valve | Automatic drainage | Automatic drainage | Automatic drainage |
| Air End | Jiayang machinery | Jiayang machinery | Jiayang machinery |
