| Model | Output | Frequeny | Pressure | Air Discharge | Voltage | Size | Speed | Weight | Tank | |||
| kW | HP | Control | bar | Psi | L/min | CFM | V/ph | cm L*W*H | r.p.m | kg | L | |
| JYWXG-0.35-8/10 | 2.2 | 3 | Power Frequency 50/60Hz | 8/10 | 116/145 | 350 | 12.3 | 220V/Single Phase 380V/Three-Phase | 104*40*110 | 2800/3400 | 155 | 100/130 |
| JYWXG-0.5-8/10 | 3 | 4 | Power Frequency 50/60Hz | 8/10 | 116/145 | 500 | 17.6 | 220V/Single Phase 380V/Three-Phase | 111*45*119 | 2800/3400 | 168 | 160 |
| JYWXG-0.66-8/10 | 4.5 | 6 | Power Frequency 50/60Hz | 8/10 | 116/145 | 660 | 23.3 | 380V/Three-Phase | 125*45*119 | 2800/3400 | 205 | 180 |
| JYWXG-1.1-8/10 | 7.5 | 10 | Power Frequency 50/60Hz | 8/10 | 116/145 | 1100 | 38.9 | 380V/Three-Phase | 128*53*127 | 2800/3400 | 260 | 230 |
| Model | Output | Frequeny | Pressure | Air Discharge | Voltage | Size | Speed | Weight | Tank | |||
| kW | HP | Control | bar | Psi | L/min | CFM | V/ph | cm L*W*H | r.p.m | kg | L | |
| JYWXG-0.28-12.5 | 2.2 | 3 | Power Frequency 50/60Hz | 12.5 | 182 | 270 | 9.5 | 220V/Single Phase 380V/Three-Phase | 105*38*99 | 2800/3400 | 135 | 100/130 |
| JYWXG-0.66-12.5/15.8 | 5.5 | 7.5 | Frequency Conversion | 12.5/15.8 | 182/229 | 600 | 21.2 | 380V Three-Phase | 127*45*110 | 3000/3600 | 200 | 180 |
| JYWXG-1.1-12.5/15.8 | 11 | 15 | Frequency Conversion | 12.5/15.8 | 182/229 | 1100 | 38.9 | 380V Three-Phase | 131*50*120 | 3000/3600 | 260 | 230 |
| JYWXG-1.4-12.5/15.8 | 15 | 20 | Frequency Conversion | 12.5/15.8 | 182/229 | 1400 | 49.5 | 380V Three-Phase | 131*50*120 | 3000/3600 | 260 | 230 |
